The easy-to-use tilt-sliding system, with integrated positive control, allows both tilting and sliding operations, making windows and doors easier to open. To open, the handle is automatically moved and slid sideways in a parallel position, saving space. To close, the sash is automatically brought into an inclined and locked position. With optimized bearing technology, this process is smooth, eliminating the need to push or pull the sash.
TECHNICAL SPECIFICATIONS
- Space-Saving Design: Provides space-saving solutions for optimal use in balcony doors.
- Integrated Positive Control: Automatically facilitates the movement of heavy sliding doors; when the handle is opened, the sash retracts into the sliding position.
- Wide Bearing Technology: High-quality 28 mm wide bearings ensure smooth and quiet operation.
- Durability for Heavy Sashes: Provides support with integrated anti-lift devices and strong bearings for sashes weighing 160-200 kg.
- Optimal Weight Management: The misoperation device minimizes sash sagging, enhancing the durability of the door.
- Self-Locking Prevention System: Features an anti-lock device with a 127° handle rotation, preventing accidental locking.
- Thermal Insulation: The 125 mm profile distance allows the use of thermally insulated windows with ease.
- Tilt Compatibility: Plastic connectors ensure a smooth connection in the tilt position.
- Hidden Entry Points: Provides easy cleaning and aesthetic responses.
- Top and Bottom Buffer: Safely stops the sash in the open position, reducing the risk of damage.
- Ventilation Capability: Provides effective ventilation in the tilt position, just like standard tilt-and-turn windows.
- Slim Profile Design: Slim profiles allow more light inside, creating brighter living spaces.
